Name: UTV ATV Battery On Board Chargers For 43.8V 30A 12S LiFePO4 Battery
Model: E15
Type: On board silver shell
AC Input: 1. US standard plug to Yeeda AC plug Y60 3.0M(3*2.08mm²). 2. Yeeda AC plug Y60 to DJ7031-4.8-21(female plug) 1.5M(3*2.5mm²). 3. AC cable connect to DJ7031Y-4.8-11(male plug) 0.5M(3*2.5mm²).
DC Output: Output cable 2.0M(2*5.26mm²) 20cm red black wires at the end of the cable to the M8 ring terminal.
Current/Voltage: 43.8V 30A (Automatic power reduction when 120V AC input)
Battery: 12S LiFePO4
Application: UTV ATV and other powersports cars
This E15 1500W series chargers’ common output is 24V 30A, 36V 30A, 48V 25A, 60V 20A, 72V 15A, 84V 13A, 96V 12A. We will customize a suitable output for you based on your battery information.
View more detailed information about E15 1500W Battery Charger
